BES4-800S60
Bessey® 4800S-60 Heavy Duty F-Style Bar Clamp 7 in D Throat 60 in Clamping Hex Head Swivel
Product information
Description
Bessey® Bar Clamp Heavy Duty F-Style Series: 4800S 7 in Throat Depth 60 in Clamping Hex Head Swivel 1-1/2 in Swivel Pad 3/4 in Screw ACME Threaded Spindle 3/4 in Spindle Diameter 7/16 in W Bar 1-37/64 in Bar Thickness Steel Bar 2-3/4 x 1-3/4 in Clamp Face 4880 lb Clamping 1-37/64 x 25/32 in Nominal Rail T-Handle Handle 6-7/8 in L Handle Steel Handle Zinc Plated
Additional details
Product details
- MorPad tilts to 35 deg patented construction extends clamp life at full capacity Forged sliding arm is made from tempered and drop forged steel for long service life High-strength electro-galvanized sliding pin T-handle rounded ends for comfort size engineered to load capacity Heat-treated high carbon ACME threaded screw - tempered and quenched to give greater load capacity with longer service life and spatter resistant The spindle has a 19 mm hexagonal head to assist in tightening and torque of 70 N-m or less
Attributes
- Bar Material: Steel
- Clamping Capacity: 60 in
- Clamping Pressure: 4880 lb
- Handle Material: Steel
- Handle Size: 6-7/8 in L
- Nominal Rail Size: 1-37/64 x 25/32 in
- Spindle Diameter: 3/4 in
- Swivel Type: Hex Head
- Throat Depth: 7 in
- Type: Heavy Duty F-Style
