ISCA-3105952
Iscar 3105952 HELIDO Indexable End Mill With Internal Coolant Channel ANSI Code: H400 ERD1.25-4-2.5W125-12 0.777 to 1.25 in Dia Cutting Welded-On Shank 0.34 in Max Depth of Cut
Product information
Description
Iscar Indexable End Mill Series: HELIDO 0.777 to 1.25 in Diameter Cutting 4.725 in Overall Length 0.34 in Maximum Depth of Cut 4 Inserts Insert Compatibility: H400 RNHU 1205 2-1/2 in Head Length 1-1/4 in Shank Diameter Welded-On Shank 2.36 in Shank Length ANSI Code: H400 ERD1.25-4-2.5W125-12 ISO Code: H400 ERD1.25-4-2.5W125-12 Yes Through Coolant
Additional details
Product details
- End mills carrying double-sided inserts with four 0.236 in radius cutting edges
Attributes
- ANSI Code: H400 ERD1.25-4-2.5W125-12
- Cutting Diameter: 0.777 to 1.25 in
- Insert Compatibility: H400 RNHU 1205
- Maximum Depth of Cut: 0.34 in
- Number of Inserts: 4
- Overall Length: 4.725 in
- Series: HELIDO
- Shank Diameter: 1-1/4 in
- Shank Type: Welded-On
- Through Coolant (Yes/No): Yes
