ISCA-3105359
Iscar 3105359 MINI-TANGSLOT Indexable Slotting Cutter ANSI Code: ETS D1.50-.250-W.625-LN08 Shank Connection 1-1/2 in Dia x 1/4 in W Cutting Right Hand Cutting LNET Insert 0.437 in Max Depth of Cut ETS-LN08 Toolholder
Product information
Description
Iscar Indexable Slotting Cutter Series: MINI-TANGSLOT 1-1/2 in Diameter Cutting 4 in Overall Length 1/4 in Cutting Width LNET Insert 3 Inserts Insert Compatibility: LNET 083504-TN-N and LNET 083704-TN-N 5/8 in Shank Diameter Welded-On Shank 3.7309999999999999 in Shank Length Right Hand Cutting Direction Shank Connection 0.437 in Maximum Depth of Cut ETS-LN08 Toolholder ANSI Code: ETS D1.50-.250-W.625-LN08
Additional details
Product details
- Grooving and slitting cutters carrying tangentially clamped inserts with 4 cutting edges
Attributes
- ANSI Code: ETS D1.50-.250-W.625-LN08
- Cutting Diameter: 1-1/2 in
- Insert Compatibility: LNET 083504-TN-N and LNET 083704-TN-N
- Maximum Depth of Cut: 0.437 in
- Number of Inserts: 3
- Overall Length: 4 in
- Series: MINI-TANGSLOT
- Shank Diameter: 5/8 in
- Shank Type: Welded-On
