ISCA-3103802 product image 0
ISCA-3103802

Iscar 3103802 FLEXFIT TORMILL Indexable End Mill ANSI Code: E93CN D1.00-4-M12-07 1 in Dia Cutting Straight Shank CNHT MT 07 Insert M12 Modular Connection 0.2 in Max Depth of Cut

Product information

Description

Iscar Indexable End Mill Series: FLEXFIT TORMILL 1 in Cutting Dia 2.24 in Overall Length 0.2 in Maximum Depth of Cut CNHT MT 07 Insert 4 Inserts 1.38 in Head Length 0.83 in Shank Dia Straight Shank ANSI Code: E93CN D1.00-4-M12-07 ISO Code: E93CN D1.00-4-M12-07 M12 Modular Connection No

LoginRequest an account

Additional details

Product details

  • End mills with FLEXFIT threaded adaptation carrying toroidal inserts (TORMILL) Modular system reduces stock cost by using same head with different shank option Enables machining with larger over hang Same head can be mounted on metric and inch combinations

Attributes

  • ANSI Code: E93CN D1.00-4-M12-07
  • Cutting Diameter: 1 in
  • Maximum Depth of Cut: 0.2 in
  • Number of Inserts: 4
  • Overall Length: 2.24 in
  • Series: FLEXFIT TORMILL
  • Shank Diameter: 0.83 in
  • Shank Type: Straight
  • Through Coolant (Yes/No): No
