ISCA-3202645
Iscar 3202645 SUMOCHAM Indexable Head Replaceable Tip Drill 0.748 to 0.783 in Drill ICP Insert 4-1/2 in OAL 1.5XD Drill Depth by Dia Ratio 19 Insert Seat 1 in Dia Shank DCN Toolholder
Product information
Description
Iscar Replaceable Tip Drill Indexable Head Series: SUMOCHAM 0.748 to 0.783 in Drill Cylindrical Shank 1 in Shank Dia 2.2 in Shank Length 1.26 in Flute Length 4-1/2 in Overall Length DCN Toolholder Type 1.26 in Maximum Drill Depth 1.5XD Drill Depth by Dia Ratio ICP Insert 19 Insert Seat Yes Through Coolant (Yes/No)
Additional details
Product details
- Feature 4 standard drilling head types for drilling on 4 different material groups
Attributes
- Drill Depth by Diameter Ratio: 1.5XD
- Drill Size: 0.748 to 0.783 in
- Flute Length: 1.26 in
- Maximum Drill Depth: 1.26 in
- Overall Length: 4-1/2 in
- Series: SUMOCHAM
- Shank Diameter: 1 in
- Shank Length: 2.2 in
- Shank Type: Cylindrical
- Through Coolant (Yes/No): Yes
