ISCA-3202489
Iscar 3202489 SUMOCHAM Indexable Head Replaceable Tip Drill 0.669 to 0.705 in Drill ICM ICP ICK ICP-2M ICK-2M FCP HCP-IQ ICG Insert 6.38 in OAL 5XD Drill Depth by Dia Ratio 17 Insert Seat 3/4 in Dia Shank DCN Toolholder
Product information
Description
Iscar Replaceable Tip Drill Indexable Head Series: SUMOCHAM 0.669 to 0.705 in Drill Weldon Flat Shank 3/4 in Shank Diameter 1.97 in Shank Length 3.47 in Flute Length 6.38 in Overall Length DCN Toolholder 3.47 in Maximum Drill Depth 5XD Drill Depth by Diameter Ratio ICM ICP ICK ICP-2M ICK-2M FCP HCP-IQ ICG Insert 17 Insert Seat Yes Through Coolant
Additional details
Product details
- Feature 4 standard drilling head types for drilling on 4 different material groups
Attributes
- Drill Depth by Diameter Ratio: 5XD
- Drill Size: 0.669 to 0.705 in
- Flute Length: 3.47 in
- Maximum Drill Depth: 3.47 in
- Overall Length: 6.38 in
- Series: SUMOCHAM
- Shank Diameter: 3/4 in
- Shank Length: 1.97 in
- Shank Type: Weldon Flat
- Through Coolant (Yes/No): Yes
