ISCA-3202451
Iscar 3202451 SUMOCHAM Indexable Head Replaceable Tip Drill 0.591 to 0.626 in Drill FCP ICK ICK-2M ICM ICP ICP-2M Insert 5.86 in OAL 5XD Drill Depth by Dia Ratio 15 Insert Seat 3/4 in Dia Shank DCN Toolholder
Product information
Description
Iscar Replaceable Tip Drill Indexable Head Series: SUMOCHAM 0.591 to 0.626 in Drill Weldon Flat Shank 3/4 in Shank Diameter 1.97 in Shank Length 3.06 in Flute Length 5.86 in Overall Length DCN Toolholder 3.06 in Maximum Drill Depth 5XD Drill Depth by Diameter Ratio FCP ICK ICK-2M ICM ICP ICP-2M Insert 15 Insert Seat Yes Through Coolant
Additional details
Product details
- Feature 4 standard drilling head types for drilling on 4 different material groups
Attributes
- Drill Depth by Diameter Ratio: 5XD
- Drill Size: 0.591 to 0.626 in
- Flute Length: 3.06 in
- Maximum Drill Depth: 3.06 in
- Overall Length: 5.86 in
- Series: SUMOCHAM
- Shank Diameter: 3/4 in
- Shank Length: 1.97 in
- Shank Type: Weldon Flat
- Through Coolant (Yes/No): Yes
