ISCA-3201847
Iscar 3201847 DR-TWIST Indexable Insert Drill 1.32 in Drill 1.654 in Modular Connection 1-1/4 in Dia Shank 3XD Drill Depth by Dia Ratio SOMT Insert 8.14 in OAL 3.84 in D Max Drill
Product information
Description
Iscar Indexable Insert Drill Series: DR-TWIST 1.32 in Drill 1-1/4 in Shank Diameter 3 in Shank Length Straight Shank 1.654 in Modular Connection SOMT Insert 3.84 in Maximum Drill Depth 8.14 in Overall Length 1.281 in Diameter 3XD Drill Depth by Diameter Ratio 2 Drill Inserts Insert Compatibility: SOMT-DT SOMT-GF 3.84 in Flute Length Yes Through Coolant
Additional details
Product details
- 1/2-14 NPT thread 1.654 in holder diameter ISO Code: DR1281-3843-125-09-3D-N
Attributes
- Drill Depth by Diameter Ratio: 3XD
- Drill Size: 1.32 in
- Flute Length: 3.84 in
- Maximum Drill Depth: 3.84 in
- Overall Length: 8.14 in
- Series: DR-TWIST
- Shank Diameter: 1-1/4 in
- Shank Length: 3 in
- Shank Type: Straight
- Through Coolant (Yes/No): Yes
