ISCA-3201843
Iscar 3201843 DR-TWIST Indexable Insert Drill 1.22 in Drill 1.654 in Modular Connection 1-1/4 in Dia Shank 3XD Drill Depth by Dia Ratio SOMT Insert 7.67 in OAL 3.38 in D Max Drill
Product information
Description
Iscar Indexable Insert Drill Series: DR-TWIST 1.22 in Drill 1-1/4 in Shank Dia 3 in Shank Length Straight Shank 1.654 in Modular Connection Size SOMT Insert 3.38 in Maximum Drill Depth 7.67 in Overall Length 1-1/8 in Dia 3XD Drill Depth by Dia Ratio Insert Compatibility: SOMT-DT SOMT-GF SOMT-HD 3.38 in Flute Length Yes Through Coolant (Yes/No)
Additional details
Attributes
- Drill Depth by Diameter Ratio: 3XD
- Drill Size: 1.22 in
- Flute Length: 3.38 in
- Maximum Drill Depth: 3.38 in
- Overall Length: 7.67 in
- Series: DR-TWIST
- Shank Diameter: 1-1/4 in
- Shank Length: 3 in
- Shank Type: Straight
- Through Coolant (Yes/No): Yes
