ISCA-3201321

Iscar 3201321 DR-TWIST Indexable Insert Drill 0.673 in Drill 1.102 in Modular Connection 3/4 in Dia Shank 3XD Drill Depth by Dia Ratio SOGX/SOMX Insert 5.56 in OAL 1.73 in D Max Drill

Product information

Description

Iscar Indexable Insert Drill Series: DR-TWIST 0.673 in Drill 3/4 in Shank Dia 3 in Shank Length Straight Shank 1.102 in Modular Connection Size SOGX/SOMX Insert 1.73 in Maximum Drill Depth 5.56 in Overall Length 0.578 in Dia 3XD Drill Depth by Dia Ratio 2 Drill Inserts Insert Compatibility: SOGX/T-AL SOMX-DT SOMX-GF SOMX-HD 1.73 in Flute Length Yes Through Coolant (Yes/No)

LoginRequest an account

Additional details

Product details

  • 0.578 in tool diameter 1/4-18 NPT thread ISO Code: DR0578-1734-075-05-3D-N

Attributes

  • Drill Depth by Diameter Ratio: 3XD
  • Drill Size: 0.673 in
  • Flute Length: 1.73 in
  • Maximum Drill Depth: 1.73 in
  • Overall Length: 5.56 in
  • Series: DR-TWIST
  • Shank Diameter: 3/4 in
  • Shank Length: 3 in
  • Shank Type: Straight
  • Through Coolant (Yes/No): Yes
