CLEC-16797
Cleveland® Q-CO" C16797 2575 Tapered Length High Performance Drill 25/64 in Drill - Fraction 0.3906 in Drill - Decimal Inch 7 in OAL M42 HSS-Co 8 Straw/Gold Oxide
Product information
Description
Cleveland® Q-CO" High Performance Drill Tapered Length Series: 2575 25/64 in Drill - Fraction 0.3906 in Drill - Decimal Inch 7 in Overall Length 3-7/16 in Cutting Depth 2 Flutes Spiral/Wide Land Parabolic Flute 3-7/16 in Flute Length 25/64 in Shank Straight Shank 135 deg Point Split Point Right Hand Cutting Direction M42 HSS-Co 8 Cutting Edge M42 HSS-Co 8 Straw/Gold Oxide Applicable Materials: Aluminum Brass Cast Iron High Carbon Steel Low Carbon Steel Med Carbon Steel Nickel Alloy Plastic Stainless Steel and Tool Steel
Additional details
Product details
- Deliver close hole tolerance for high precision work Use higher speeds and feeds for increased productivity 38 deg helix -0.001 in drill diameter tolerance +/-0.125 in overall length tolerance +/-0.125 in flute length tolerance +/-5 deg point angle tolerance
Attributes
- Applicable Materials: Aluminum Brass Cast Iron High Carbon Steel Low Carbon Steel Med Carbon Steel Nickel Alloy Plastic Stainless Steel and Tool Steel
- Cutting Direction: Right Hand
- Cutting Edge Material: M42 HSS-Co 8
- Finish: Straw/Gold Oxide
- Flute Length: 3-7/16 in
- Material: M42 HSS-Co 8
- Overall Length: 7 in
- Point Angle: 135 deg
- Point Type: Split
- Shank Type: Straight
