CLEC-15263
Cleveland® Q-Cobalt" C15263 2175-TC High Performance Screw Machine Drill 17/64 in Drill - Fraction 0.2656 in Drill - Decimal Inch M42 HSS-Co 8 TiCN Coated
Product information
Description
Cleveland® Q-Cobalt" Screw Machine Drill High Performance Series: 2175-TC Imperial 17/64 in Drill - Fraction 0.2656 in Drill - Decimal Inch 2-5/8 in Overall Length 5XD Cutting Depth 2 Flutes Right Spiral/Wide Land Parabolic Flute 1-7/16 in Flute Length 17/64 in Dia x 1-3/16 in L Shank Straight Shank 135 deg Point Split Point Right Hand Cutting Direction M42 HSS-Co 8 Cutting Edge M42 HSS-Co 8 TiCN Coated Applicable Materials: Chilled Cast Iron High-Strength Alloy Steel Stainless Steel and Tool Steel
Additional details
Product details
- Effective deep hole drilling in a wide array of materials Shorter design for accuracy and rigidity
Attributes
- Applicable Materials: Chilled Cast Iron High-Strength Alloy Steel Stainless Steel and Tool Steel
- Cutting Direction: Right Hand
- Cutting Edge Material: M42 HSS-Co 8
- Finish: TiCN Coated
- Flute Length: 1-7/16 in
- Material: M42 HSS-Co 8
- Overall Length: 2-5/8 in
- Point Angle: 135 deg
- Point Type: Split
- Shank Type: Straight
