CLEC-17571
Cle-Line® COMBIDISC® C17571 1850 Imperial Backing Pad Pointed End Cone - Pointed (Shape SM) Head 1/4 in Dia Head 1 in L of Cut 2 in OAL Double Cut
Product information
Description
Cle-Line® COMBIDISC® Backing Pad Imperial Series: 1850 Pointed End 1/4 in Diameter Head 1 in Length of Cut 2 in Overall Length Cone - Pointed (Shape SM) Head Shape Double Cut 1/4 in Shank Diameter Solid Carbide Head Bright Head Coating 10 deg Included Angle 70000 rpm Maximum Applicable Materials: Brass Bronze Cast Iron Fiberglass Inconel Malleable Iron Masonite Steel Alloy Carbon Steel Stainless Steel and Titanium Industry Specification: SM-3
Additional details
Product details
- The double cut style has right and left hand helical flutes combined to produce a chisel type cutting tooth Results in faster penetration and stock removal with minimal bounce or chatter Results in higher productivity with less operator fatigue and a good finish on a variety of workpiece materials
Attributes
- Applicable Materials: Brass Bronze Cast Iron Fiberglass Inconel Malleable Iron Masonite Steel Alloy Carbon Steel Stainless Steel and Titanium
- Cut Type: Double
- Head Diameter: 1/4 in
- Head Material: Solid Carbide
- Head Shape: Cone - Pointed (Shape SM)
- Industry Specification: SM-3
- Length of Cut: 1 in
- Maximum Speed: 70000 rpm
- Shank Diameter: 1/4 in
- Type: Imperial
